Portable drug detection equipment
Parameter configuration and performance description: The Portable Raman Spectrometer is a special security inspection instrument for anti-terrorism detection, anti-drug and anti-epidemic, used for the detection of liquid, solid, powder, water solution and other forms of explosives, drugs, precursor chemicals, alcohol and Psychotropic Drugs and other samples of Raman Spectrum. The equipment adopts the most advanced laser Raman spectrum analysis method, which integrates sampling, detection, spectrum scanning processing, database searching, similarity contrast and identification.The Portable Raman Spectrometer is small in size, light in weight, easy to carry, simple in operation, and can be used for rapid analysis of components accurately. Raman Spectroscopy one-click detection, identification built-in more than 200 kinds of targeted contraband database cloud platform computing and storage, follow-up can achieve large-scale data mining and computing system built-in GPS, GPRS, Bluetooth, WI-FI and other means of communication 5.6-inch capacitance high-definition display, friendly man-machine interface built-in VT and other high-end Raman Spectral Processing Algorithms, similarity and peak-seeking and reverse-gate recognition algorithms to achieve component-level independent domestic R & D and production of IP65 industrial-grade waterproof rechargeable lithium battery life > 5hr,Most drugs, such as heroin/morphine, cocaine, papaverine and other precursors of most drugs, such as acetone. Explosives such as toluene, most commercial and military explosives such as TNT, (Jo) Polyol, c 4(plastic explosives) , TNTB, nitrocellulose, nitroguanidine and other drugs, most commonly used drugs, such as Cephalosporin, Amoxicillin, Tinidazole, Ofloxacin, acafenol powder, (headache powder) and so on.
Physical parameters, whole size: 180 * 95 * 38 MM Whole Weight: & Lt; 800G INPUT INTERFACE: Micro USB performance parameters, spectral range: 200cm-1 ~ 3200cm-1 wavelength resolution: 15cm-1@1000cm-1 excitation wavelength: 785 ± 0.5 nm, linewidth < 0.1 NM LASER LIFETIME: 10, 000.00HRS POWER SUPPLY VOLTAGE: OUTPUT POWER OF DC5V ADAPTER: 0 ~ 500mW adaptive integral time: 1ms-10S adaptive probe Rayleigh scattering cutoff depth: OD6 probe working focal length: 7.5 mm camera: 8 megapixel touch screen: 720 * 1280 resolution capacitance screen 3 protection standard: IP65 network: 4g/WIFI/bluetooth/GPS environment parameters, operating temperature: 0 ~ 45 °C operating humidity: 5%-80%
Parameters configuration and performance description: Criminal Detection: Illicit Drugs, drug detection in the field: Drug Analysis and identification, raw and auxiliary materials in the field, rapid analysis of JEWELRY/ORE: Minerals, gemstones in the field identification materials: Material Analysis Specifications Physical parameters machine size 160 * 222 * 74mm machine weight 2.3 kg performance parameters spectral range 200-3900cm-1 resolution 8-10cm-1 laser wavelength 785nm detector, high sensitivity CCD detector laser power 0-500 NW adjustable display 5.6 inch high-definition color touch screen service life 10,000,00 hrs integral time 7.2 ms-5s probe working focal length 10 mm data USB input output power 12V/3a power adapter battery, rechargeable lithium battery life > 5 HR Environmental Parameters working/storage temperature 0-45 °C working/storage humidity 5%-80% detectable substance type drug, most drugs such as heroin/morphine, cocaine, papaverine and most other precursors, such as acetone. Explosives such as toluene, most commercial and military explosives such as TNT, (Jo) Polyol, c 4(plastic explosives) , TNTB, nitrocellulose, nitroguanidine and other drugs, most commonly used drugs, such as CEPHALOSPORIN, Amoxicillin, Tinidazole, Ofloxacin, acafenol powder, (headache powder) and so on
Colors and styles can be customized
