Body Armor
Parameter configuration and performance description: 1, material: 41 layers of high performance polyethylene fabric (four layers of orthogonal fiber) + 1 layer of 5mm thick foam; 2, Protection Area: 0.27 m 23, protection level: 1-3 level 4, color: police blue, camouflage 5, implementation standards: In line with the “GA141-2010 police body armor”standard. Our company provides 2013 Special Police Equipment Quality Supervision and Inspection Center issued by the Ministry of Public Security Qualified Test report, and with a certificate; product Liability Insurance: 6 million yuan, insurance period of 8 years.
Product Features: 1, this section of bullet-proof clothing wear flexible, easy to wear off. The free movement of two arms and human body kneeling, jumping, squatting, pitching, turning are not restricted after wearing. The jacket of the body armor is designed to meet the specifications of the body layer components and can be quickly separated. The body layer components are marked with the impact or close-to-the-body surface. 2, this section of body armor jacket without damage, floating line, needle leakage and other defects. Bullet-proof layer material surface without holes, deep pits, scratches, cracks and other defects, corner Burr, metal materials rust-proof treatment, non-metallic materials uniform level. The same layer of bullet-proof material is uniform, without splicing, local uplift, wrinkles and other defects. By the multi-layer ballistic material composition of the ballistic layer, each layer of the same size and specifications. The structure and material of the body armor attachment shall be consistent with that of the body armor. The body armor shall bear a clear and permanent mark of the product, the location of the body armor mark is 10 cm below the inside neckline of the back and in the middle of the body armor and on the bullet-proof protective sleeve. The body armor mark includes the name or trademark of the manufacturer, the product name and code number, and the product number, product specifications, implementation standard number, protection level, production date, production batch, validity period, use instructions and matters needing attention.3, bullet-proof layer protective sheathing material performance: bullet-proof layer protective sheathing is black, not pervious to light and sealed not pervious to water, sealing edge is even and consistent. The material of bullet-proof protective cover has the property of anti-seepage and anti-static water pressure ≥18 KPA. 4. Protective Area: the actual projected protective area of the body of this body armor is 0.27 M2; for body armor of Grade 5 and above, if a bullet-proof insert plate is used, it shall be placed on the outer side of the bullet-proof layer. The effective bullet-proof dimension of the bullet-proof insert plate is 250 mm × 300 mm, corner Chamfer less than or equal to 25 mm. 5. BULLET-PROOF PERFORMANCE: the 1979 type 7.62 mm light submachine gun and the 1951 type 7.62 mm pistol bullet (steel core) were used in the test. In the case of effective hit, the bullet-proof jacket should block the warhead, and the maximum depth of the back lining depression was 14.3 mm. 6. Water Resistance: At Room temperature, after the body armor is immersed in water for 30 minutes, the body armor is tested for its ballistic resistance. Under the condition of effective hitting, the body armor should block the warhead, and the maximum depth of the back lining depression is 16.7 mm. 7. Environmental Adaptability: A, after high temperature test (55 °C ± 2 °C, constant temperature 4H) , the ballistic performance test is carried out within 15 minutes. Under the effective hitting condition, the bullet-proof clothing should block the bullet, and the maximum depth of the back lining depression is 17.0 mm. B, the ballistic performance test is carried out within 15 minutes after the low temperature test (- 20 °C ± 2 °C, constant temperature 4H) . Under the effective hitting condition, the bullet-proof clothing should block the bullet, and the maximum depth of the back lining depression is 15.7 mm. C、 damp heat test (70 °C ± 2 °C, relative humidity 80% , 240h) , then put at room temperature for 24h, and the bullet proof performance test was carried out. Under the effective hitting condition, the bullet proof clothing should block the bullet, and the maximum depth of the back lining depression was 14.4 mm.
1. Material: 41 layers of high performance polyethylene fiber weft free cloth (four layers of fiber orthogonal) 1 layer of 5mm thick foam; 2, structure: bulletproof layer structure from the impact surface to start: 41 layers of high-performance polyethylene fiber weft free cloth (4 layers of fiber orthogonal) 1 layer of 5mm thick foam.
Parameter configuration and performance description: 1. Front piece: Mass: 1.5 Kg Protection Area: 0.14 M2 distance: 5 M Angle: 0 ° , left 30 ° right 45 ° , total firing 6 times, bulletproof clothing did not penetrate, depth of indentation of backing material ≤25mm measured value 3-10mm2, back piece: Mass: 1.34 kg, protective area: 0.12 M2, firing distance: 5m, Firing Angle: 0 ° , left: 30 ° , right: 45 ° , firing 6 times, bulletproof clothing did not penetrate, 4.2-11.7 mm measured depth ≤25mm for backing material. Test Basis: GA141-2010《 police body armor 》 EXECUTIVE STANDARD: Accord with 《 GA141-2010 police body armor 》 standard. Our Company provides the test report issued by the test and test center of China South Industries Group and the quality supervision and test center of China’s special weapons and equipment, and has the certificate of conformity. Product Process and materials: Material: The product consists of a coat, a protective layer and a protective cover. The protective layer is made of 38 layers of aramid UD (surface density: 8.1 kg/m2) , 0.5 MMPC and 7 MMEVA.
Parameter configuration and performance description: 1. MATERIAL: bullet-proof layer structure from the bullet-hit surface is: 50 layers of high-performance Fiber weft-free fabric (each layer of weft fabric is made of 1 layer of Aramid fiber and 1 layer of polyethylene fiber orthogonal composite) + 3mm thick foam. 2, Protection Area: 0.30 M23, protection level: three, against Type 79 light submachine gun or type 517.62 mm pistol lead cartridge. Color: Blue, camouflage; Weight: 3KG5; Implementation Standard: Meet The “GA141-2010 police body armor”standard. My company provides after 2015 the Ministry of Public Security Special Police Equipment Quality Supervision and Inspection Center, the China South Industries Group test and Test Center, the China Ordnance Equipment Special Product Quality Supervision and Inspection Center issued the qualified test report, and has the qualified certificate; Product Liability Insurance: 6 million yuan, insurance life of 8 years.
Product Features: 1, this section of bullet-proof clothing layer of the main materials selected Aramid weft-free fabric and high-performance polyethylene weft-free fabric orthogonal heat. Reasonable combination of polyethylene fiber light weight, ultraviolet resistance, aramid fiber deformation after the advantages of small bullet, excellent bullet-proof performance excellent bullet-proof performance, wear flexible, easy to wear off. The free movement of two arms and human body kneeling, jumping, squatting, pitching, turning are not restricted after wearing. The jacket of the body armor is designed to meet the specifications of the body layer components and can be quickly separated. The body layer components are marked with the impact or close-to-the-body surface. 2, this section of body armor jacket without damage, floating line, needle leakage and other defects. Bullet-proof layer material surface without holes, deep pits, scratches, cracks and other defects, corner Burr, metal materials rust-proof treatment, non-metallic materials uniform level. The same layer of bullet-proof material is uniform, without splicing, local uplift, wrinkles and other defects. By the multi-layer ballistic material composition of the ballistic layer, each layer of the same size and specifications. The structure and material of the body armor attachment shall be consistent with that of the body armor. The body armor shall bear a clear and permanent mark of the product, the location of the body armor mark is 10 cm below the inside neckline of the back and in the middle of the body armor and on the bullet-proof protective sleeve. The body armor mark includes the name or trademark of the manufacturer, the product name and code number, and the product number, product specifications, implementation standard number, protection level, production date, production batch, validity period, use instructions and matters needing attention.3, bullet-proof layer protective sheathing material performance: bullet-proof layer protective sheathing is black, not pervious to light and sealed not pervious to water, sealing edge is even and consistent. The material of bullet-proof protective cover has the property of anti-seepage and anti-static water pressure ≥18 KPA. 4. Protective Area: the actual projection protective area of the body of this body armor is 0.3 M2; for body armor of Grade 4 and above, if the body armor plate is used, it should be placed on the outer side of the bulletproof layer. The effective bulletproof dimension of the bulletproof plate is 250 mm × 300 mm, corner Chamfer less than or equal to 25 mm. 5. BULLET-PROOF PERFORMANCE: the 1979 type 7.62 mm light submachine gun and the 1951 type 7.62 mm pistol bullet (lead core) were used in the test. Under the effective hitting condition, the bullet-proof jacket should block the bullet head, and the maximum depth of the back lining depression ≤25 mm. 6. Water Resistance: At Room temperature, after the body armor is immersed in water for 30 minutes, the body armor is tested for its ballistic resistance. Under the condition of effective hitting, the body armor should block the bullet, and the maximum depth of the back lining depression is less than 25 mm. 7. Environmental Adaptability: A, after high temperature test (55 °C ± 2 °C, constant temperature 4H) , the ballistic performance test should be carried out within 15 minutes. In case of effective hitting, the bullet-proof clothing should block the bullet, and the maximum depth of the back lining depression ≤25 mm. B, after the low temperature test (- 20 °C ± 2 °C, constant temperature 4H) , the ballistic performance test is carried out within 15 minutes. Under the effective hitting condition, the bullet-proof clothing should block the warhead, and the maximum depth of the back lining depression is ≤25 mm. C, wet heat test (70 °C ± 2 °C, relative humidity 80% , 240h) , then put at room temperature for 24h, and the bullet proof performance test was carried out. Under the effective hitting condition, the bullet proof clothing should block the bullet, and the maximum depth of the back lining depression is less than 25mm.
Product process and material: 1, material: bulletproof layer structure from the elastic surface to start: 50 layers of high-performance fiber weft cloth (each layer of weft cloth by 1 layer of Arlene fiber and 1 layer of polyethylene fiber orthogonal composite production) 3mm thick foam; 2, structure: bulletproof layer structure from the impact surface of the sequence: 50 layers of high-performance fiber weft cloth (each layer of weft cloth by a layer of Arlene fiber and a layer of polyethylene fiber orthogonal composite production) 3mm thick foam.
Colors and styles can be customized
